BOSCH REXROTH
3842535572
$10.58
- BOSCH REXROTH
- Material:3842535572
- Model:INSIDE BRACKET 10
Quantity in stock: 5
| Profile finishing: not required |
| Especially suitable for constructing frames for doors, protective grilles, or partition walls |
| The inner bracket, 6 mm slot, can also be used as an inner bracket R, 6 mm slot |
| Profile finishing: not required |
| Data Sheet | Download Data Sheet |
| 3D CAD | Download 3D CAD |
| Bending moment 1 | 100 |
| Productgroup ID | 2 |
| Packaging unit | 10 |
| ESD | yes |
| Material | Cast steel, galvanized |
| Weight | 0.053 |
| Scope of delivery | Incl. fastening material |
| Material information | Inner bracket: Cast steel, galvanized,Fastening material: Steel, galvanized |
| Fastening material | 2x headless setscrew ISO 913 M8x12 |
| Profile slot | 10 |
|
Nut |
|
|
|
8 / 8 |
2200 N |
50 Nm |
|
10 / 10 |
2800 N |
100 Nm |
Inner bracket, slot 6/6
Inner bracket, slot 8/8
Inner bracket, slot 10/10
|
FS1 |
FS2 |
FS3 |
|
|
|
