BOSCH REXROTH
PANEL CONNECTOR
3842542736


$4.79
  • BOSCH REXROTH
  • Material:3842542736
  • Model:PARALLEL CONNECTOR 10

Quantity in stock: 6



Parallel connector N10

Unpacked Weight: 0.042 kg
For gap-free connecting of two strut profiles, parallel to the axis or at any angle
Parallel connector consisting of two sliding blocks with welded springs for simple assembly
Attractive-looking interior connection, e.g. for material shelves
Connection possible in any position
Transferable displacement force per parallel connector: 600 N
Profile finishing: through-hole
Data Sheet Download Data Sheet
3D CAD Download 3D CAD
Productgroup ID2
Packaging unit10
Length [l]20
Diameter D9.8
MaterialSteel, galvanized
Weight0.042
Scope of deliverySliding block with spring, Swivel-in sliding block with spring, Countersunk screw M5
Material informationSliding block: Steel, galvanized,Spring: Spring steel, stainless
Profile slot10

No.

Material

3842542737 Sliding block: steel; galvanized
Spring: spring steel; stainless
3842542736
technical illustration-PANEL CONNECTOR-Parallel connector N10
technical illustration-PANEL CONNECTOR-Parallel connector N10

Parallel connector

technical illustration-PANEL CONNECTOR-Parallel connector N10

Scope of delivery

Parallel connector N8 sliding block with spring, swivel-in sliding block with spring, countersunk screw M5
Parallel connector N10
